Features:
- Horizontal square inner chamber + jacket structure, safety, heat preservation, and drying function
- Disc type embedded gear + Electric lock door structure, safety and reliable
- The door seal is pneumatic, single or double door(double door interlock)
- Equipped with standard equipment verification interface
- Pipeline system for the optimal design, SUS304 pipeline, clamp structure, quick assembly
- Control system: HMI man-machine interface, touch screen+PLC
- F0 value and temperature time double guarantee sterilization effect, with perfect sterilization records
- With program selection, parameter setting, equipment operation, report processing and traceability Functions
- Three levels of authority management
- Multiple safety protection(over-temperature, over-pressure protect)
- Sterilization process: fabric, equipment, liquid, BD, pressure testing, custom-defined multiple procedures
Technical parameters:
- Design pressure: -0.1~0.3Mpa
- Working pressure:0.245Mpa
- Vacuum:-0.086Mpa
- Water pressure:0.1-0.2Mpa
- Steam Pressure: 0.3~0.7Mpa
- Design temperature:144℃
- Working Temperature:105~138℃
- Compressed air pressure:0.4~0.7Mpa
- Power Voltage: Three-phase five-wire AC 380V 50Hz
Packing Details:
- Overall Dimension(L*W*H) (mm) 1175×1130×1760mm
- Chamber Dimension(L*W*H) (mm) 925×450×480mm
- Net weight (kg):880kg
